H05 IP66 Waterproof Entry Door Smart Lock

·Tuya video intercom: See at First Knock, Talk in Real Time - Your Eyes at the Door, Instantly.

·3D facial recognition and palm verification: enable hands-free access

·IP66 Certified Protection: Sandstorm & Rain Proof

·12-Language Voice Guide: Instant Clarity for Global Users

·Semiconductor Sensor: Live fingerprint scanning, blocks fake prints

·Security Features: Dual Authentication & Virtual Password Shield & Anti-pry alarm

Model		H05
Material		Aluminum alloy
Surface technology		Painting
Color		Matte Black
Unlocking Methods	Outdoor	FaceId / Palm vein / Fingerprint / Password / iCcard / Mechanical key
	Indoor	Handle / Button
User capacity	FaceId/Palm vein	50	300 in total
	Fingerprint	100
	Password	Up to 200
	iCcard	Up to 200
Main power supply		4200mA lithium battery
Battery life		3 months
Emergency power supply		5V power bank
Fingerprint sensor type		Semiconductor sensor
Working temperature		-25°C ~ +70°C
Working humidity		15%RH ~ 93%RH
Door thickness		38-120mm
Door types		Security doors, wooden doors, stainless steel doors, copper-clad doors, etc.
Compatible Lock Body Types		Single Point Lock/Multi-Point Lock/Double Hook Lock
Network		TUYA(optional)
Accessories		6068 Single Point Lock Body * 1
		Silicone pad * 2
		IC card * 2
		Lock cylinder * 1
		Hardware pack * 1
		Instruction manual * 1
		Drilling template * 1
		USB Type-C charging cable * 1

Introduction

The H05 smart lock stands like a vertical technological sentinel. On its front panel, the top infrared recognition module scans discreetly, instantly identifying familiar faces. The digital keypad, when lit up, resembles a constellation of stars in the night sky, enabling clear and precise password entry. Hidden on the back of the handle is a fingerprint sensor—a light touch awakens a sense of exclusive trust, while a colorful light strip glows like a welcoming ribbon, illuminating the moment of access.

The rear panel features a screen that functions like a smart mirror, allowing a clear view of outside activity with a single press. The square handle evokes a sturdy shield, offering a solid grip and clean-edged design.

Like a silent security steward, the lock utilizes its technological eyes, fingers, and shields to turn every entry into a reassuring embrace.
